YS12KIT Stainless Steel Exhaust kit for Yanmar YS-12 series
$420.00
This HDI Marine part replaces YANMAR P/N 124070-13520 & 104511-13070
OVERVIEW
- ***THIS DOES NOT FIT THE QM, GM, YM, HM, YS8 SERIES ENGINES***
- This HDI Marine item replaces Yanmar PN 104511-13070 (lower elbow) & 128990-13520 / 104214-13531 / 128370-13610 / 124070-13520 / 128270-13600 / 128370-13600 (mixing elbow)
- Fits the following engines: YSE-12 / YSB-12 / YSM-12
- Precision CNC machined investment cast 316 stainless steel
- Includes yellow zinc plated stainless steel nipple as shown in photos replaces Yanmar PN 104214-13580 ($29.25 value)
- This assembly is shipped hand-tight, with proper anti-seize applied to the threads. Will need tightened with tools before install.
- Includes bronze hose barb (water connection) that replaces Yanmar PN 124070-13300 ($27.90 value)
- DOES NOT INCLUDE gasket for mounting at this time
- 1-1/4 BSPT
- 3/8” pipe thread water inlet (5/8″ hose)
- 2” OD discharge diameter with 1-1/4 BSPT ID
- Product weighs 7.5 lbs (3.4kg)
- Shipping weight is 10 lbs (4.5kg)
